Chauvin Arnoux PEL 103 Power & Energy Logger
The Chauvin Arnoux PEL 103 is an ergonomic, triple-phase power and energy logger designed to monitor electrical installations across industrial, commercial, and residential facilities. Featuring a backlit digital display, it records voltage, current, power ratings, energy consumption, power factor, and harmonics up to the 50th order—all without requiring a power outage during installation.
Equipped with a magnetic back for easy mounting inside switchboards, the PEL 103 simplifies long-term energy audits and power quality troubleshooting. Captured data is automatically stored on an internal SD card and can be transferred via USB, Ethernet, or Bluetooth. Paired with the PEL Transfer software, facility managers and electrical technicians can easily configure the device, visualize real-time measurements, and generate automated energy compliance reports.
Key Highlights
-
Comprehensive Power Measurement: Records RMS voltage, current, active/reactive/apparent power (VA, W, var), active/reactive/apparent energy (VAh, Wh, varh), PF, DPF, and tan φ.
-
Non-Intrusive Installation: Compact housing with a magnetic back panel allows secure attachment directly inside steel electrical cabinets.
-
Harmonics Analysis: Measures total harmonic distortion (THD) and individual harmonics up to the 50th order for both voltage and current.
-
Multiple Network Compatibility: Suitable for single-phase, split-phase, and 3-phase (balanced or unbalanced) electrical configurations without neutral.
-
Versatile Connectivity: Supports USB, Ethernet, and Bluetooth for remote monitoring, real-time data streaming, and seamless file retrieval.
-
PEL Transfer Software Included: Enables user-friendly setup, historical trend analysis, cost tracking, and automated reporting.
Applications & Benefits
-
Facility Energy Audits:
-
Tracks real-time and long-term energy consumption to uncover power waste and optimize energy efficiency.
-
-
Sub-Metering & Cost Allocation:
-
Allocates electrical expenses accurately across different departments, production lines, or tenant spaces.
-
-
Power Quality & Harmonics Monitoring:
-
Identifies harmonic distortion generated by non-linear loads (VFDs, UPS systems, and IT infrastructure) to prevent transformer overheating and equipment trips.
-
Technical Specifications
| Parameter / Feature | Specification |
| Supported System Types | Single-phase, split-phase, 3-phase (with or without neutral), and DC systems |
| Number of Channels | 3 voltage inputs, 3 current inputs |
| Voltage Range | Up to 1,000 V RMS (CAT IV 600 V / CAT III 1,000 V) |
| Current Range | Depends on sensor attached (e.g., AmpFlex® / MiniFlex® up to 10,000 A AC) |
| Frequency Range | 50 Hz, 60 Hz, and 400 Hz (DC to 400 Hz) |
| Display | 4-line triple digital display with blue backlight |
| Harmonics Measurement | Up to the 50th order (Voltage and Current) |
| Storage | SD / SDHC Card slot (Supports up to 32 GB) |
| Communication Protocols | USB, Ethernet (RJ45), Bluetooth |
| Power Supply | External mains adaptor or self-powered via voltage inputs (Mains adapter accessory required) |
| Safety Rating | IEC 61010 600 V CAT IV / 1,000 V CAT III |
| Protection Degree | IP54 (Dust and splash resistant) |
| Dimensions & Weight | 256 mm x 125 mm x 37 mm / Approx. 950 g |
Standard Package Kit
-
Chauvin Arnoux PEL 103 Power & Energy Logger Unit
-
4x Voltage Test Leads & Alligator Clips
-
2 GB SD Card (or higher)
-
USB Cable & Power Cord
-
Safety Sheet & Test Report
-
PEL Transfer Software (Downloadable / CD)
-
Carrying Bag / Storage Case
Maintenance & Handling
Clean the housing and display window using a soft cloth slightly dampened with soapy water. Do not use solvent-based cleaners. Ensure test leads and current clamp connectors are free from debris before connecting them to voltage terminals.
Available accessories include:
-
AmpFlex® / MiniFlex® Flexible Current Sensors
-
MN / MA Series Current Clamps
-
Self-Power Adapter for PEL Loggers
-
Magnetic Mount Accessories & Spare Test Lead Kits
