Modern telecommunications infrastructure and data centers require high network reliability, low latency, and continuous bandwidth expansion. The viavi mts 5822p Dual-Port Handheld Network Tester delivers a compact, field-ready testing solution designed to help network technicians install, commission, maintain, and troubleshoot optical and Ethernet networks efficiently.

viavi mts 5822p 10G Dual-Port Architecture for Field Efficiency

The core strength of the viavi mts 5822p lies in its dual-port SFP/SFP+ design. Featuring two independent transceiver slots, the unit supports simultaneous bi-directional traffic testing up to 10 Gbps without requiring two separate test sets. Field technicians can run inline network monitoring, measure round-trip latency, and generate dual-stream traffic on a single handheld device, cutting down testing times and minimizing trial errors.

Multi-Protocol & Multi-Rate Support

Engineered for modern multi-service networks, this field tool supports a wide array of protocols and transmission rates:

• Ethernet Testing: Full rate testing from 10 Mbps, 100 Mbps, 1 GbE, up to 10 GbE (10GBASE-X).

• Fibre Channel: Validates Storage Area Networks (SAN) across 1G, 2G, 4G, 8G, and 10G speeds.

• Mobile Fronthaul: Supports CPRI and OBSAI protocol testing up to Rate Option 8 (10.1 Gbps) for 4G LTE and 5G mobile backhaul/fronthaul validation.

• Transport Networks: Comprehensive testing for OTN (OTU1, OTU2, OTU1e, OTU2e) and SONET/SDH (up to OC-192/STM-64).

Automated Industry Standard Workflows

To simplify complex field procedures and ensure Service Level Agreement (SLA) compliance, the viavi mts 5822p includes automated testing suites:

• ITU-T Y.1564 (SAMComplete): Evaluates all SLA parameters—throughput, frame loss, latency, and packet jitter—simultaneously across multiple service flows.

• RFC 2544: Standardized benchmarking for Ethernet throughput, latency, packet loss, and back-to-back frames.

• RFC 6349 (TrueSpeed): Automated Layer 4 TCP throughput testing that measures real-world end-user connection speeds.

Physical Layer Diagnostics & Optics Inspection

Because physical layer defects remain a primary cause of network downtime, the MTS-5822P integrates directly with physical optics inspection tools:

• Connector Inspection: Pairs with the VIAVI P5000i digital probe to perform pass/fail fiber end-face analysis based on IEC 61300-3-35 standards.

• OTDR & Optical Power Meter Expansion: Connects with VIAVI OTDR modules and power meters to measure optical attenuation, locate fiber breaks, and map link topology.

Ruggedized Design for On-Site Operations

Built to handle harsh field environments, the unit features a lightweight, durable chassis with a bright touchscreen display for clear visibility. Long battery life ensures continuous operation across cell towers, central offices, and data center environments.

Key Technical Specifications

• Model: viavi mts 5822p

• Form Factor: Handheld Dual-Port Transport & Network Tester

• Interfaces: 2x SFP/SFP+ ports (10M to 10G)

• Protocols: Ethernet (10M–10G), OTN, SONET/SDH, Fibre Channel, CPRI/OBSAI

• Test Suites: Y.1564, RFC 2544, RFC 6349, Bit Error Rate Testing (BERT), Loopback

• Display: High-resolution color touchscreen

• Connectivity: USB, Ethernet Management, optional Wi-Fi/Bluetooth

Primary Applications

• Metro Ethernet Turn-Up: Verifies link performance and SLA compliance for ISPs and enterprise network deliveries.

• Cell Site Maintenance: Validates CPRI link integrity and latency between Baseband Units (BBU) and Remote Radio Heads (RRH).

• Data Center Interconnects: Tests 10G Ethernet and Fibre Channel storage links between server racks or facilities.

• Network Troubleshooting: Quick isolation of packet loss, signal degradation, or fiber plant faults.

The viavi mts 5822p provides network engineers and field technicians with an accurate, dual-port tool to verify network performance and maintain uptime across 10G transport infrastructure.
